    125℃-150℃阻燃热缩套管



    耐高温阻燃热缩管是一种采用高能电子轰击交联的 环保性聚烯烃热缩材料制成,限制PBB、PBD、 PBBE类及重金属等对环境有害的物质,耐高温阻燃 热缩管燃烧时不产生二恶英,具有柔软、耐腐蚀、 阻燃、耐高温、绝缘等特点。

    High temperature resistant flame-retardant heat shrinkable tube is made of environmentally friendly polyolefin heat shrinkable material, restriction of PBB, PBBD, PBBE and heavy metals and other harmful substances in the environment, high temperaturere resistant flame-retardant heat shrinkable tube combustion does not produce dioxin, with soft, corrosion resistant flame retardant, high temperature resistance, insulation and other characteristics.


    特性(Features)

    阻燃、柔软、绝缘、低温收缩达到UL224标准,标准型耐压600V,薄璧型耐压300V,标准型尺寸 中Φ30以上,耐电压可达到1KV。 Flame retardant, soft, insulation, low temperature shrinkage, reach Ul224 standard. Standard type pressure 600V, thin wall pressure 300V, the standard size which is more than Φ30, high voltage can reach 1KV.

    收缩比率( 2:1;3:1;4:1):Shrinkage ratio 2:1;3:14:1

    纵向收缩率( Longitudinal shrinkage):<±5%

    最低收缩温度( Minimum shrinkage temperature):90℃

    连续使用温度( Continuous use temperature):- 55℃-125℃- 559℃- 135℃;-55℃-150℃

    环保性能符合欧盟ROHS, REACH等指令( Environmental protection performance in line with the EU ROHS, REACH, etc.)
